The next generation in the Lockwood Panic Exit Device range, the FLUID series provides for the fundamental means of escape whilst offering a unique locking mechanism and design aesthetic. With this type of unique innovation, ASSA ABLOY continues to evolve in standardising the market. The Lockwood FLUID Exit Device range combines ergonomics and performance with a completely new axis mechanism and a high-security bolt system.
The FLUID Exit Single Point Series is a one-point locking device that provides an escape function at all times by pushing a horizontal bar fitted to the door.
Successfully tested on fire door assemblies in accordance with Australian Standard AS1905.1-2005, Fire Resistant Doorsets. Conforms to the standard as set out in CE, EN1125-2008.
Cylinder Dogging
The Cylinder Dogging device is a simple mechanism designed to hold the push bar in the open position. Ideal for applications where access to the premises can be selected at any time and providing for a common thorough fare door.
With the innovative locking mechanism integral to the FLUID Exit range, the latches are always retained behind their strike plate providing a positive latched state to the door as all times. The Cylinder Dogging option will not change the state of latch and for this reason, we are able to provide this option as successfully tested on fire doors for the first time. NB L9555-502 Euro Half Cyl sold separately
Note:
Door size up to 1200mm.
Single-point rim locking.
Tested to 1.000.000 cycles.
Auxiliary bolt activation from 1mm.
Effortless opening <20N required.
The bar can be cut down to 350mm.
New Fixing bracket and template design reduces installation time by up to 50%.
Cylinder dogging an optional accessory.
Protect evacuating people safely.
Secure high vandal resistance.
Half cylinder sold separately, if required.
Lead times are listed under additional information
For applications requiring an external trim, please order separately FE5000SIL Series trim kit
Cylinder Dogging
The Cylinder Dogging device is a simple mechanism designed to hold the push bar in the open position. Ideal for applications where access to the premises can be selected at any time and providing for a common thoroughfare door.
The Cylinder Dogging device can be ordered inclusive with the FLUID Exit Device, or can be supplied as an optional accessory.
External
Access can only be achieved from exterior face, when lever handle is added
Warranty
25 Year mechanical
Returns Policy
Purchased to order item, therefore this item is non-returnable.
$503.41–$728.24Price range: $503.41 through $728.24 incl GSTSelect options
This product has multiple variants. The options may be chosen on the product page
$415.44–$542.51Price range: $415.44 through $542.51 incl GSTSelect options
This product has multiple variants. The options may be chosen on the product page
Lockwood Fluid Single Panic Exit Device
$1,077.54 – $1,708.35Price range: $1,077.54 through $1,708.35 incl GST
Description
The next generation in the Lockwood Panic Exit Device range, the FLUID series provides for the fundamental means of escape whilst offering a unique locking mechanism and design aesthetic. With this type of unique innovation, ASSA ABLOY continues to evolve in standardising the market. The Lockwood FLUID Exit Device range combines ergonomics and performance with a completely new axis mechanism and a high-security bolt system.
The FLUID Exit Single Point Series is a one-point locking device that provides an escape function at all times by pushing a horizontal bar fitted to the door.
Successfully tested on fire door assemblies in accordance with Australian Standard AS1905.1-2005, Fire Resistant Doorsets. Conforms to the standard as set out in CE, EN1125-2008.
Cylinder Dogging
The Cylinder Dogging device is a simple mechanism designed to hold the push bar in the open position. Ideal for applications where access to the premises can be selected at any time and providing for a common thorough fare door.
With the innovative locking mechanism integral to the FLUID Exit range, the latches are always retained behind their strike plate providing a positive latched state to the door as all times. The Cylinder Dogging option will not change the state of latch and for this reason, we are able to provide this option as successfully tested on fire doors for the first time.
NB L9555-502 Euro Half Cyl sold separately
Note:
Door size up to 1200mm.
Single-point rim locking.
Tested to 1.000.000 cycles.
Auxiliary bolt activation from 1mm.
Effortless opening <20N required.
The bar can be cut down to 350mm.
New Fixing bracket and template design reduces installation time by up to 50%.
Cylinder dogging an optional accessory.
Protect evacuating people safely.
Secure high vandal resistance.
Half cylinder sold separately, if required.
Lead times are listed under additional information
Finish: Silver
Additional information
Assa Abloy
Silver
LWFE109 OHSIL 900mm, LWFE112 OHSIL 1200mm, LWFE109 1HSIL 900mm Cylinder Dogging, LWFE112 1HSIL Cylinder Dogging
Euro profile cylinder sold separately
For applications requiring an external trim, please order separately FE5000SIL Series trim kit
The Cylinder Dogging device is a simple mechanism designed to hold the push bar in the open position. Ideal for applications where access to the premises can be selected at any time and providing for a common thoroughfare door.
The Cylinder Dogging device can be ordered inclusive with the FLUID Exit Device, or can be supplied as an optional accessory.
Access can only be achieved from exterior face, when lever handle is added
25 Year mechanical
Purchased to order item, therefore this item is non-returnable.
Allow 7-14 working days
Lockwood Panic Exit Devices Fluid
DownloadFLUID Panic Exit Instructions
DownloadQR Code
